AX3000 Dual Band Gigabit Wi-Fi 6 Router_U350P-18

Highlight Features

  • Dual-core ARM cortex A9 RISC (1.1GHz)
  • Low Cost Wi-Fi 6 AX3000 platform from Chinese Vendor
  • High-integration with small board size
  • Can add support for GPON/SLIC VOIP feature for customized need

Contact us for the stock and customized requirements!

Product Details:

Specifications

Chipset CPU: TRI ductor VSPM350P Dual-core ARM cortex A9 RISC (1.1GHz)

WIFI6:TR5220

System Memory Default DDR3 256Mbyte (Optional 512Mbyte)
SPI NAND Flash Default 128Mbyte (Optional 256Mbyte~1Gbyte)
Expansion 1x USB 3.0 connector
Wireless  MU-MIMO 802.11a/b/g/n/ac/ax WiFi 6

2.4GHz 2T2R 576Mbps, B mode@22dBm(Max)

5.8GHz 2T2R 2.4Gbps, A mode@21.5dBm(Max)

Wired Interface 4x Gigabit 1*WAN+3*LAN
Reset Button 1x Factory Restore Button (GPIO)
DC Power 1x DC Jack Connector (Default 12V@1A)
Power Consumption 9 W(Max),12V@1A in full range
Software Linux
Environmental Temperature: Operating: 0ºC to 50ºC, Storage: -40ºC to 90ºC

Humidity (non-condensing): Operating: 5% to 95%, Storage: Max. 95%

Baseboard Dimensions: 110x80x15mm

VSPM350P Block Diagram

Board Block Diagram

Customization Options

Uiotin have engaged in providing global customers with professional ODM/OEM service of customized stable and

cost-effective electronic products. We can customize total production for the customer including Chassis, Hardware,

Software and Package as below customization options for this product. Contact us at sales@uiotin.com for more

detailed info.

Name Customization Comments Uiotin Customization
Memory Change to 512Mbyte Supported
SPI NAND Flash Change to 256M~1Gbyte Supported
Case Select the different case material for your application Supported

Ordering Information

Models Comments
U350P-18 128Mbyte SPI NAND Flash and 256Mbyte DDR3 RAM
